Technical Specifications & Features
| 1 | MEMORY | 499 PROGRAMS’ STORAGE |
| 2 | TURN SET EACH PROGRAMMES | 99.999 MAX TURNS |
| 3 | PRODUCTION COUNTING | PROVIDED |
| 4 | POWER FAIL | COUNTER WILL NOT RESET |
| 5 | TRAVERSE MOVING WIDTH | 99.9 MM MAX |
| 6 | WIRE GAUGE | 45 SWG TO 25 SWG |
| 7 | WIRE CUT INDICATION | PROVIDED |
| 8 | TRAVERSE MOTOR | STEPPER MOTOR WITH DRIVE |
| 9 | SPINDLE MOTOR | 180V-180W 3000 PMDC MOTOR WITH DRIVE |
| 10 | BRAKE WITH CLUTCH | 12V ELECTROMAGNETIC |
| 11 | WINDING PITCH ADJUST | PROVIDED ONLINE KEY |
| 12 | EVERY LAYER STOP | ON/OFF. INDICATION ONLINE |
| 13 | DISPLAY | 20X4 COLOUR LCD DISPLAY |
| 14 | JOG SPEED 01-15% CAN SET | ONLINE KEY PROVIDED - ON/OFF |
| 15 | SUPPLY | 220V 50HZ 1 Phase |
| 16 | WINDING SPEED- 6000 MAX | VARIABLE BY UP/DOWN KEY |
| 17 | TOTAL TAPS | 8 TAPS EACH PROG PROVIDED |
| 18 | BOBBIN WIDTH | 99.9MM PROVIDED |
| 19 | BOBBIN DIAMETER | 60mm MAX |
| 20 | TOTAL SPINDLE | 4 SPINDLE WITH 4 WIRE GUIDE UNIT |
| 21 | ACCELARATION TIME | PROGRAMMABLE |
| 22 | DE ACCELARATION TIME | PROGRAMMABLE |
| 23 | ONLINE TURNS INDICATION | 0.1 TURNS ACCURACY |
| 24 | CONTROLLER SECURITY | PASSWORD OPTION PROVIDED |
| 25 | MACHINE SIZE | LXWXH - 600X600X500 HT |
| 26 | STANDARD ACCESSORIES | MOTOR BELT, WIRE TENSIONER STAND, ALLEN KEYS, POWER CORD, WIRE CUT CABLE |
| 27 | WARRANTY | 1 YEAR FROM THE DATE OF SUPPLY |
| 28 | MACHINE SIZE- LxWxH | 600x600x1000MM (Table size required 3ft-3ft) |
| 29 | TOTAL WEIGHT | 80 Kgs |
| 30 | WARRANTY | 1 YEAR FROM THE DATE OF DELIVERY |
