16 | Winding Speed | Variable By Up/Down Key Max- 1500 Rpm |
17 | Supply | 220v 50hz 1 Phase |
18 | Core Index Motor | Hybrid Stepper Motor |
19 | Online Core Adjustment | Switch Provided |
20 | Machine Speed Limit | Slider -1500rpm- Belt Type-500rpm |
21 | Shuttles Available | 3,4,5,6,7,8,Mm Extra Cost |
22 | De Accelaration Turns | Programmable 5-25 Turns |
23 | Turns Indication | Display Shown Online |
24 | Controller Security | Password Option Provided |
25 | 0.7mm Nylon Sliders | Available On Extra Cost |
26 | Automatic Stop | After Loading& Winding |
27 | Core Positioning | Online Adjustable By Keys |
28 | Machine Size | 600x1000x500mm Height |
29 | Machine Weight | 50 Kgs |
30 | Prog Inter Link | Prog No 001 To 499 |
30 | Std Tools With Machine | Power Cord,Allen Keys,Spanner & Felt & Belts
|
31 | Switches | Load/Wind/Start/Stop/4 Way Joystick Lever Type
|
