Technical Specifications & Features
| 1 | Memory | 499 Programs’ Storage |
| 2 | Turn Set Each Programmes | 99.999 Max Turns |
| 3 | Production Counting | Provided |
| 4 | Power Fail | Counter Will Not Reset |
| 5 | Traverse Width(Bobbin) | 99.9mm Max |
| 6 | Online Traverse Adjust | Stop The Machine Then Press Lh/Rh Keys |
| 7 | Wire Cut Indication | Provided |
| 8 | Traverse Motor | Stepper Motor With Drive |
| 9 | Spindle Motor | 0.5 Hp Ac Motor With Drive |
| 10 | Brake With Clutch | 12v Electromagnetic |
| 11 | Winding Pitch Adjust | Provided Online Key |
| 12 | Every Layer Stop | On/Off. Indication Online |
| 13 | Display | 20x4 Colour Lcd Display |
| 14 | Jog Speed 01-15% Can Set | Online Key Provided - On/Off |
| 15 | Supply | 220v 50hz 1 Phase |
| 16 | Winding Speed | Variable By Up/Down Key 1500/3000/6000 |
| 17 | Total Taps | 8 Taps Each Prog Provided |
| 18 | Wire Gauges | 40 Swg To 14 Swg |
| 19 | Bobbin Swing Diameter | 20 To 100mm Provided |
| 20 | Coil Weight | Max 5 Kgs |
| 21 | Accelaration Time | Programmable |
| 22 | De Accelaration Time | Programmable |
| 23 | Online Turns Indication | Yes |
| 24 | Controller Security | Password Option Provided |
| 25 | Machine Size – | Lxwxh - 900x900x500 Ht |
| 26 | Standard Accessories | Motor Belt, Wire Tensioner Stand, Allen Keys, Power Cord, Wire Cut Cable |
| 27 | TOTAL WEIGHT With Stand | 80 Kgs |
| 28 | Warranty | 1 Year From The Date Of Delivery |
