Technical specification and programming data/ features
| 1 | MEMORY | 499 PROGRAMS’ STORAGE |
| 2 | TURN SET EACH PROGRAMMES | 99.999 MAX TURNS |
| 3 | PRODUCTION COUNT | PROVIDED |
| 4 | POWER FAIL SAVE | COUNTER WILL NOT RESET |
| 5 | WIRE GAUGE | 40 SWG- 18SWG |
| 6 | CORE OUTER DIAMETER | 30-120 MM DIAMETERS |
| 7 | CORE INNER DIAMETER | 15 MM-100MM |
| 8 | CORE HEIGHT | 10MM-50MM |
| 9 | SHUTTLE DRIVE MOTOR | 0.5HPbAC MOTOR WITH VFD |
| 10 | SEGMENT WINDING | PROVIDED 360 DEGREES |
| 11 | WINDING PITCH ADJUST | PROVIDED ONLINE |
| 12 | EVERY LAYER STOP | ON/OFF. INDICATION ONLINE |
| 13 | DISPLAY | 20X4 COLOUR LCD DISPLAY |
| 14 | JOG SPEED | ONLINE KEY PROVIDED |
| 15 | SUPPLY | 220V 50HZ 1 Phase |
| 16 | WINDING SPEED | VARIABLE BY UP/DOWN KEY |
| 17 | TOTAL TAPS | 8 TAPS EACH PROG PROVIDED |
| 18 | CORE INDEX MOTOR | HYBRID STEPPER MOTOR |
| 19 | ONLINE CORE ADJUSTMENT | SWITCH PROVIDED |
| 20 | WINDING SPEED | SLIDER -1800RPM- BELT TYPE-500RPM |
| 21 | SHUTTLES AVAILABLE | 8 .10.12.16MM EXTRA COST |
| 22 | DE ACCELARATION | PROGRAMMABLE |
| 23 | TURNS INDICATION | 5TURNS ACCURACY |
| 24 | CONTROLLER SECURITY | PASSWORD OPTION PROVIDED |
| 25 | 0.7MM NYLON SLIDERS | AVAILABLE ON EXTRA COST |
